Input:

• Capacity: 2000 VA / 1200 W

• Voltage: 110/120 VAC or 220/230/240 VAC

• Voltage range: 81-145 Vac / 162-290 VAC

• Frequency range: 60-50 Hz (auto sensing)

  Output:

• Output voltage: 110/120 or 220/230/240 VAC

• AC voltage regulation (Batt. Mode): ± 10%

• Frequency range (Batt. Mode): 50 Hz or 60 Hz ± 1 Hz

• Transfer time: Typical 2-3 ms

• Waveform (Batt. Mode): Simulated sinewave

  Battery:

• Battery type & number: 12 V/9 Ah x 2

• Typical recharge time: 4-6 hours recover to 90% capacity

  Protection:

• Full protection: overload, discharge and overcharge protection

  Indicators:

• AC mode: Green lighting

• Battery mode: Yellow flashing

• Fault: Red lighting

  Alarm:

• Battery mode: Sounding every 10 seconds

• Low battery Sounding every second

• Overload: Sounding every 0.5 second

• Fault: Continuously sounding

  Physical:

• Dimension: D x W x H (mm): 320 x 130 x 182

• Net weight (kgs): 10.6

  Environment:

• Humidity: 0-90 % RH @ 0-40°C (non-condensing)

• Noise leverl: less than 40 dB
