Input:

• Capacity: 10000 VA / 9000 W
• Nominal Voltage: 3×400 VAC (3Ph+N)
• Frequency range: 46-54 Hz or 56-64 Hz

Output:

• Output voltage: 208/220/230/240 VAC
• AC voltage regulation (Batt. Mode): ± 1%
• Frequency range (Batt. Mode):46-54 Hz or 56-64 Hz
• Current crest ratio: 3:1 (max.)
• Waveform (Batt. Mode): Pure sinewave

Battery:

• Battery type: 12 V/7 Ah
• Typical recharge time: 9 hours recover to 90% capacity
• Charging Voltage: 273 VDC ± 1% (Based on 20pcs batteries)

Indicators:

• LCD Display: UPS status, Load level, Input/Output voltage, Discharge timer, and Fault conditions

Alarm:

• Battery mode: Sounding every 4 seconds
• Low battery Sounding every second
• Overload: Sounding twice every second
• Fault: Continuously sounding

Physical:

• Dimension: D x W x H (mm): 592x250x576
• Net weight (kgs): 83
