Rated Power – 3000VA/3000W

Voltage – 230 VAC

Selectable Voltage Range – 170-280 VAC (For Personal Computers); 90-280 VAC (For Home Appliances)

Frequency Range – 50 Hz/60 Hz (Auto sensing)

AC Voltage Regulation (Batt. Mode) – 230VAC ± 5%

Surge Power – 6000VA

Efficiency (Peak) – 93%

Transfer Time – 10 ms (For Personal Computers); 20 ms (For Home Appliance)

Waveform – Pure sine wave

Battery Voltage – 24 VDC

Floating Charge Voltage – 27 VDC

Overcharge Protection – 32 VDC

Solar Charger Type – MPPT

Maximum PV Array Open Circuit Voltage – 450 VDC

Maximum PV Array Power – 3000W

Maximum PV Input Current – 13A

MPP Range @ Operating Voltage – 30 ~ 400 VDC (30 ~ 60VDC with battery connected)

Maximum Solar Charge Current – 100A

Maximum AC Charge Current – 80A

Maximum Charge Current – 100A

Dimension, D x W x H (mm) – 110 x 288 x 390

Net Weight (kgs) – 7.2

Communication Interface – RS232/RS485, optional WiFi

Humidity – 5% to 95% Relative Humidity (Non-condensing)

Operating Temperature: -10°C to 50°C

Storage Temperature: -15°C to 50°C
